Specifications
► Processor: Embedded NS Geode GXLV 300MHz
► Chipset: NS CS5530A
► Memory: One 144-pin SODIMM socket up to 128MB
► BIOS: Award Flash BIOS
►
IDE interface: One Enhanced Ultra DMA33 Interface that supports a 2.5" hard drive
► Graphics:
- NS CS5530A (graphics built in to chipset)
- Shared memory up to 4MB
- Supports VGA
- GST CyberPro 5005 with 4MBDRAM (Bravo 200T)
- NTSC/PAL TV output Composite and S video connectors (Bravo 200T)
► LAN:
Realtek 8139C 10/100 Base-T with RJ-45 connector
► SSD: Compact Flash Disk or Disk on Chip
► Expansion Card solution: PCMCIA type I/II
► Watchdog Timer: Software selectable time-out interval, generates a system reset or IRQ11
►
High Speed Multi I/O:
- 2 x RS-232, with D-Sub 9 pin connector
- 1 x LPT ; Supports SPP/EPP/ECP
- 1 x KB , 1 x Mouse
- 2 x USB
- 1 x IrDA
► Audio Interface: Line out supports a 0.5W speaker, Line in and Microphone in
► Hardware Monitoring: FAN monitoring with sound alarm
► Power Adaptor: AC input AC100~240V, Output DC 5V/6A
► Operating temperature:
0 to 60 deg.C ( 32 to 140 deg.F )
► Power Requirements: 5V @ 6 amp (External power adapter included)
► Supported OS: Windows 95/98/NT/ME/2000/CE, Linux, Novell
► Dimension: (HxWxD) 1.6 x 7.4 x 5.9 (40mm x 188mm x 150mm)
►
Weight: 0.95Kg ( 2.1lbs.)
► Drive Bay: One 2.5" Internal Bay for HDD
|
