Specifications:

CPU

Intel socket 478 P4 Prescott, Celeron D with 800/533 FSB with Hyperthreading

CPU speed

Up to 3.4 Ghz

FSB speed

800/533 Mhz

Chipset

Intel 915GV + ICH6

Memory

2 DDR 184 pin sockets for PC2700/333 Mhz or PC3200/400 Mhz DDR ram

Video

Intel Graphics on chipset, DVI option

Serial ATA drives

4 SATA 150 connectors

IDE drives

1 IDE connector for 2 drives

Floppy Drive

1 floppy connector

Compact Flash

Digital I/O

8 (4inputs and 4 outputs)

Audio

AC’97 with optional connector bracket

LAN Port

1 Ethernet marvell 8053 PCI express Gigabit controller

Keyboard + Mouse

1 PS2 connector cable for keyboard and mouse

USB Ports

8 USB 2.0

Serial Ports

2 RS232 serial ports

IrDA

1

Parallel Port

1

Watchdog

For software hangups, programmable 1 - 255 sec

Power Requirement

12v@9.0A,+5@8.1A,-12v@0.3A,5VSB@0.4A, P4 Prescott 3.4 Ghz, 2Gb RAM Ram

Hardware Monitor

monitors fans, temperatures and voltages

Operating Temp.

0 to 60 deg C

Relative Humidity

0 to 95% non-condensing

Dimension

4.8” x 13.425” (12.2cm x 34.1cm)

Weight

1.3lbs (0.6kg) board only / 3 lbs (1.2kg) shipping weight
