Specifications:

LCD Display

31.51" WXGA Color TFT-LCD Module

Display Area

697.68 (H) x 392.62 (V) mm

Brightness

500 cd/m2 (Typ.)

Max. Resolution

1366 x 768 (WXGA)

Contrast Ratio

800:1

Response Time (Typ.)

24 ms (Typ.)

Pixel Pitch(mm)

0.51075 mm

Display Colors

16.7 M

Viewing Angle

+85 ~-85 (H), +85 ~-80 (V)

Horizontal/Vertical Frequency

Hf:80KHz; Vf: 56~75Hz

Pixel Frequency

PC Connector

D-sub 15 Pin (VGA input)

Video Output (option)

Signal Connector (Video)

AV/S-Video/Component/TV Tuner

Audio Output

10W x 2

TV-Tuner (option)

AC/DC Power Adapter Input

AC 100~240V, 50~60 Hz

AC/DC Power Adapter Output

Power Consumption

200W (Typ.)

Temperature Range of Operation

Accessory

Dimension (mm)

820 (H) x 530 (V) x 110.6 (D)mm

Weight (Net)

45lbs and 51 lbs shipping weight (20.6 kgs/23.2kgs)

Inverter

Option
